Used used skid steer wheel loader For Sale

Pictures available:

Details:
  • Category:  Loader
  • Brand:  CASE
  • Model:  CASE 95XT
  • Year:
  • SN:
  • price($):  contact us

Description

Case 95XT Skid Steer Loader

Dimensions

Dimensions

A Length with Bucket   11.91 ft in

B Width Over Tires   6.01 ft in

C Height to Top of Cab   6.67 ft in

Wheelbase  4.2 ft in

E   Ground Clearance   9.1 in

F   Length w/o Bucket    9.22 ft in

G   Clearance at Max Lift and Dump    7.91 ft in

H   Reach at Max Lift and Dump   36.82 in


Specifications Engine

 Number of Cylinders 4

Engine Make 2239

Engine Model  4T-390
 Gross Power   85 hp
 Net Power  74 hp
 Power Measured @   2500 rpm
 Displacement  239 cu in
Aspiration  Turbocharged

Operational

Operational Weight    9050 lb

 Fuel Capacity   20.1 gal

Cooling System Fluid Capacity   4.4 gal

 Engine Oil Fluid Capacity   2.8 gal
 Hydraulic System Fluid Capacity   17.6 gal
 Chain Box Fluid Capacity - each side   2.1 gal
 Max Speed   11.1 mph
 Tire Size   15.5x16.5
 Operating Voltage 12 V

Alternator Supplied Amperage  65 amps

Loader Breakout Force 5800

 Operating Load Rating  3150 lb

Tipping Angle  6300 degrees

Bucket Capacity  0.8 yd3

Hydraulic Pump Type

gear pump with integrated constant pressure valve

Pump Flow Capacity  27.6 gal/min

Relief Valve Pressure 3002 psi

Dimensions

Length with Bucket  12 ft in

Length w/o Bucket  9.3 ft in

Width Over Tires  6.1 ft in

Height to Top of Cab 6.7 ft in
 Clearance at Max Lift and Dump 8 ft in
 Wheelbase 4.2 ft in
 Ground Clearance 9.1 in
 Reach at Max Lift and Dump 36.9 in
 Turning Radius from Center - machine rear 65 in
Turning Radius from Center - inc bucket  86.3 in
