Used CaterpillarCAT D11R Dozer For Sale

Details:

Description

Cat: Crawler Dozer

Brand : Caterpillar

Model: CAT D11R

This unit is in good working condition and ready for sale.

Specification (For reference only)

Engine
Make	Caterpillar
Model	3508B
Gross Power	915 hp	682.3 kw
Net Power	850 hp	633.8 kw
Power Measured @	1800 rpm
Displacement	2105.3 cu in	34.5 L
Number of Cylinders	8
Aspiration	Turbocharged and Aftercooled
Operational
Operating Weight	225500 lb	102285.1 kg
Fuel Capacity	388.6 gal	1471 L
Cooling System Fluid Capacity	61 gal	231 L
Engine Oil Capacity	28 gal	106 L
Hydraulic Fluid Capacity	54.2 gal	205 L
Powertrain Fluid Capacity	90.9 gal	344 L
Final Drives Fluid Capacity	7.9 gal	30 L
Operating Voltage	24 V
Alternator Supplied Amperage	100 amps
Transmission
Type	Power shift
Number of Forward Gears	3
Number of Reverse Gears	3
Max Speed - Forward	7.3 mph	11.7 km/h
Max Speed - Reverse	8.7 mph	14 km/h
Undercarriage
Ground Pressure	23.6 psi	162.5 kPa
Ground Contact Area	9781 in2	6.3 m2
Standard Shoe Size	28 in	710 mm
Number of Track Rollers per Side	8
Track Gauge	9.5 ft in	2890 mm
Standard Blade
Width	20.8 ft in	6350 mm
Height	93.3 in	2370 mm
Capacity	45 yd3	34.4 m3
Cutting Depth	30.2 in	766 mm
